Schrader Road Bike Valve TR1

Schrader Road Bike Valve TR1

  • Tr No.:TR1
  • Stem material:Brass
  • Rubber: Nature,Butyl
  • Cold inflation pressure maximum: Up to 110Psi/7.5Bar
  • Components:brass stem,rubber base,nut,core,cap

Description

TR NO.ETRTORim HoleABBase ODCoreNutCapCold inflation pressure maximum
TR1-18-8.3~8.64.526.518PD(G)/EP2TD(G)/ND(G)EG110PSI(7.5Bar)
TR1-20-8.3~8.64.526.520PD(G)/EP2TD(G)/ND(G)EG110PSI(7.5Bar)
TR1-22-8.3~8.64.526.522PD(G)/EP2TD(G)/ND(G)EG110PSI(7.5Bar)
TR1-25-8.3~8.64.526.525PD(G)/EP2TD(G)/ND(G)EG110PSI(7.5Bar)
TR1-28-8.3~8.64.526.528PD(G)/EP2TD(G)/ND(G)EG110PSI(7.5Bar)
TR1-32-8.3~8.64.526.532PD(G)/EP2TD(G)/ND(G)EG110PSI(7.5Bar)
TR1-22X28-8.3~8.64.526.522X28PD(G)/EP2TD(G)/ND(G)EG110PSI(7.5Bar)
TR1-20X32-8.3~8.64.526.520X32PD(G)/EP2TD(G)/ND(G)EG110PSI(7.5Bar)

Specification

*All valves are 100% verified for air-tightness.
Have fulfilled the requirements for ISO/TS16949 certification by TUV management services.
